Bare Die Fixed Filters

MFHP-00040CH

Passive GaAs MMIC 29.16 GHz Highpass Filter

The MFHP-00040CH is a passive MMIC surface mount highpass filter that is an ideal solution for small form factor, high rejection filtering. The MFHP-00040CH features a 29.16 GHz 3 dBc cutoff and 23 dB passband return loss. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFHP-00040CH is available as a wire-bondable die. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.
