MFBC-00009CH

Passive GaAs MMIC 46.50-63.50 GHz Bandpass Filter

The MFBC-00009CH family of passive MMIC bandpass filters are an ideal solution for small form factor, mmWave, high rejection filtering. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. Low unit-to-unit variation allows for accurate simulations using the provided S2P file taken from measured production units. The MFBC-00009CH is available as a wire bondable die.

Product Variant : MFBC-00009CH
Sorted by: No sorting applied
MFBC-00009CH
Bandpass
40.4046.1046.9054.1262.4464.72See plot2.32.20 x 2.20 mmReleased

Technical Resources
