MFBB-00001CH

Passive GaAs MMIC 14.60 – 15.65 GHz Bandpass Filter

The MFBB-00001CH family of passive MMIC bandpass filter die are an ideal solution for small form factor, high rejection filtering. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit to unit variation than traditional filter technologies. The MFBB-00001CH is available as a wire bondable chip. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

Product Variant : MFBB-00001CH
Sorted by: No sorting applied
MFBB-00001CH
Bandpass
13.9914.4514.6615.1415.6315.8016.632.63.10 x 2.30 mmReleased

Technical Resources
