MFB-2625CH

Passive MMIC 20.5-32 GHz Bandpass Filter

The MFB-2625 is a passive MMIC bandpass filter. It is a low loss integrated filter that passes K to Ka-Band frequencies (20.5-32GHz). Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit to unit variation than traditional filter technologies. The MFB-2625 is available as a wire bondable chip. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

Product Variant : MFB-2625CH
Sorted by: No sorting applied
MFB-2625CH
Bandpass
16.9220.7821.7825.7030.3231.6638.861.41.25 x 1.25 mmReleased

Technical Resources
